Cylindrical Roller Bearing NU Series

Model: NU234C3FY
Price Each: 4,885.36
Total Price: $4,885.36
Quantity:


Product Details

Manufacture:  Koyo

ID MM:  170

OD Decimal:  12.2047

OD MM:  310

W MM:  52

W Decimal:  2.04724

ID Decimal:  6.6929

Retainer:  Rivet type Machined Brass

Weight:  39.7

Cylindrical Roller Bearings
  • NU - Separable inner ring,no thrust load capacity.
  • NJ - Separable inner ring, thrust load capacity in one direction.
  • NUP - Separable inner ring with loose rib on one side, thrust load capacity in both directions.
  • NN - Double row, Separable outer ring.
See the Cylindrical roller bearing dimensional data sheet for description and configuration design).
Configurations having integral flanges or loose ribs on both the inner and outer rings can sustain a small amount of axial load. Since this bearing type supports axial loads as sliding action between the end of the rollers and flange faces, axial loading is limited.
