SS6800 Series

Model: 6804-LLB
NTN BEARING Made in Japan
Price Each: 9.88
Total Price: $9.88
Quantity:

Product Details

Bore MM:  20

Bore Decimal:  0.7870

OD MM:  32

OD Decimal:  1.2590

W MM:  7

W Decimal:  0.2755

ABEC:  ABEC-1

Enclosure:  Double Sealed

Interchange:  MRC 1804-SZZ, SKF 61804-2RS

Weight:  0.040

6804-LLB NTN JAPAN Bearing
The deep thin-walled ball bearings of 6804-LLB series will bear moderate axial load as well as radial load. The 6800 has a lower coefficient of friction and higher speed rating compared to other ball bearing types of the same size. When the use of a thrust type ball bearing is not suitable due to high speeds the 6800 series can be used to bear pure axial loads. The 6800 series is available in open, sealed or shielded configurations.
